ATV Snowplow

Products description:

ATV Snowplow

Model no.: SJ-D0150

Vehicle technical specification:
Engine brand: Zongshen, water-cooled single cylinder, four-stroke
Displacements: 250cc
Forward/Re speeds: 4 forward, 1 neutral and 1 reverse
Start mode: Electrical start
Fuel capacity: 10L
Vehicle speed: 3-10km/h
Brake system: Front and reak brake disc
Load capacity: 200kg
Seats: 2 People
Snow clearing technical specification:
Area sweep (Max): 3600-26000 ㎡/H
Rear engine brand: Longcin 420cc, OHV, 4 stroke
Power: 9.0kW/3600rpm
Transmission mode: Electronic clutch
Working width: 150cm / 59″
Brush diameter: 55cm / 21.7″
Brush rotate speed: 400rpm (max)
Working head adjustable angle: Left 25 degrees, right 25 degrees
Easy fast assembly: Yes
Packing: Iron rack + wooden box
Cer.for Europe: CE Standard
PCS/Carton: 1PC/2Carton
G./N. Weight: 600/500kg
Carton size: 300*150*110cm
Warranty: One year
Loading 20’/40’/40HQ: 6/13/15pcs
